Bookeye Book Scanner

The Bookeye Color Planetary Book Scanner has revolutionized the way that information found in books, newspapers, delicate over-sized documents, and 3-D objects is captured. Bookeye makes scanning in color, black and white, or grayscale a snap. You can even choose to scan once and create both color and grayscale or other output combinations.

Bookeye's book scanner overhead scan design and scan/print electronics with auto-focus and book-fold correction not only prevent damage to delicate books, but also make using Bookeye® easier and more efficient than normal scanners. With powerful functions like automatic removal of unsightly borders and Automatic Document Location (ADL), Bookeye® has redefined the industry standards.

Download Bookeye Book Scanner Brochure as an Adobe PDF

Features Bookeye Book Scanner

  • Book scanner 24-bit Color, Bitonal and Grayscale Output, Separately or Simultaneously
  • Batch Scanning for Continuous Scanning of Books in Production Environments
  • Alternate Scan Left and Right Page
  • Text and Photographic Scan Modes
  • Photo Reproduction Mode
  • Automatic White and Color Balance
  • Auto-Focus with 4-inch Depth of Field
  • Border Recognition and Removal
  • Minimal Maintenance Required
  • Optional Foot Pedal

Scan books, catalogs, newspapers, magazines, large-format documents, bound, clipped and
stapled material.

Thanks to Bookeye®'s rich functionality, you can achieve high throughput with bound and stapled documents while maintaining high image quality.

Technical Specifications

Resolution 300 DPI
Scan Modes Text, Photo
Compatibility Standard Network Card
Dimensions (H/W/D) 35 x 27 x 27 inches
Weight (includes packing) 94 lbs
Electrical Voltage Range 120V AC
Frequency Range 50 Hz
Power Operating Max: 400 VA
Temperature 25 to 100 F
Noise Level 45 dbA
Relative Humidity 20% - 80% (non-condensing)

Overview of Most Common Originals

  • Colored architectural plans
  • Colored wiring diagrams
  • Advertisements and sketches
  • Colored newspapers and periodicals
  • Books
  • Maps and drawings
  • Atlases
  • Ancient manuscripts
  • Surveys with photos
  • Quality control and documentation
  • Graphical designs

Overview of Main Book Scanner Functions

  • Format selection up to DIN A2 (17x24”)
  • 35 mega-pixel resolution
  • 30 bit color depth internally, 24 bit externally
  • Automatic exposure control
  • Autofocus
  • Automatic page separation
  • Automatic book-fold correction
  • PDF conversion
  • Simple installation
  • Self calibrating
  • User friendly

Scanning

  • Resolution: 200, 300, 400, 600 dpi
  • Scantime:
    o 2 sec DIN A4 portrait
    o 2,2 sec DIN A3 landscape
    o 3 sec DIN A2 landscape
  • Color depth (internal/external) 30 bit/24bit
